Asus ROG STRIX Z790-I GAMING WIFI Gaming Desktop Motherboard

Marketing Information

ROG STRIX Z790-I GAMING WIFI

Rules are made to be broken. Smashing the conventions of what a mini-ITX motherboard can do, the ROG Strix Z790-I's power delivery rivals that of full-scale titans and its stacked thermal array is more than a match for multi-core behemoths. It also expands the boundaries of connectivity, with the innovative ROG Hive, a hybrid audio and USB hub with an added twist - an AI Overclocking button makes tuning so easy, it feels like cheating. This platform delivers the power and connectivity that advanced AI PC applications demand.

ALL-ROUND PERFORMANCE

Throughout its compact frame, the Strix Z790-I teems with engineering tweaks that boost CPU and memory performance ...and lay a potent foundation for full-size SSDs and graphics cards.

AI OVERCLOCKING

Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits. Predicted values can be engaged automatically or used as a launching ground for further experimentation.

LEADING CONNECTIVITY

The ATX experience thoughtfully scaled into mini-ITX: grace your desktop with the ROG Strix Hive for superb audio and control, build easier with the ROG FPS-II card, and make faster connections with the latest Thunderbolt and WiFi support.

ROG STRIX HIVE

The all-new ROG Strix Hive brings critical controls and I/O within arm's reach, moving them from the cramped quarters of an SFF chassis to a compact peripheral that sits on the desktop. DIY-friendly buttons and diagnostic LEDs are brought front and center along with a large volume dial. On the sides, a varied group of I/O ports handle audio input and output and provide convenient connectivity for grab-and-go peripherals.

Specifications
Manufacturer: ASUS Computer International
Manufacturer Part Number: 90MB1CM0-M0EAY0
Manufacturer Website Address: http://uk.asus.com
Brand Name: Asus ROG
Product Line: Strix
Product Model: Z790-I GAMING WIFI
Product Name: STRIX Z790-I GAMING WIFI Gaming Desktop Motherboard
Product Type: Gaming Desktop Motherboard
Technical Information
AI-powered: Yes
Processor & Chipset
Chipset Manufacturer: Intel
Chipset Model: Z790
Processor Socket: Socket LGA-1700
Processor Generation Supported:

• 13th Gen
• 12th Gen
• 14th Gen

Processor Supported:

• Core
• Pentium Gold
• Celeron

Memory
Number of Memory Slots: 2
Memory Form Factor:

• DIMM
• UDIMM

Maximum Memory Supported: 96 GB
Memory Technology: DDR5 SDRAM
Memory Speed Supported:

• 7000 MHz
• 6800 MHz
• 6600 MHz
• 6400 MHz
• 6200 MHz
• 6000 MHz
• 5800 MHz
• 5600 MHz
• 5400 MHz
• 5200 MHz
• 5000 MHz
• 4800 MHz
• 7600 MHz
• 7400 MHz
• 7200 MHz

I/O Controller
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels:

• 0
• 1

Video
Onboard Video: CPU Dependent Video
Network & Communication
Bluetooth: Yes
Bluetooth Standard: Bluetooth 5.3
Gigabit Ethernet: Yes
2.5Gigabit Ethernet: Yes
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax
I/O Expansions
Total Number of Expansion Slots: 1
PCI Express Standard: PCI Express 5.0
Total Number of PCI Express Slots: 1
Number of PCI Express x16 Slots: 1
Interfaces/Ports
Total Number of USB Ports: 9
Number of USB 2.0 Ports: 2
Number of USB 3.2 Gen 1 Type-A Ports: 1
Number of USB 3.2 Gen 2 Type-A Ports: 3
S/PDIF: Yes
VGA: Yes
HDMI: Yes
HDMI Version: 2.1
DisplayPort: Yes
Number of Network (RJ-45) Ports: 1
Thunderbolt: Yes
Number of Thunderbolt 4 Ports: 2
Onboard Interfaces
Number of SATA Interfaces: 2
Number of M.2 Interfaces: 2
Total Number of Onboard USB Ports: 3
Number of Onboard USB 2.0 Ports: 3
Physical Characteristics
Form Factor: Mini ITX
Width: 170.2 mm
Depth: 170.2 mm
Miscellaneous
Package Contents:

• STRIX Z790-I GAMING WIFI Gaming Desktop Motherboard
• 2 x SATA 6Gb/s cables
• 1 x ROG USB2.0 splitter cable
• 1 x Panel Cable
• 1 x ROG FPS-II Card
• 1 x ROG STRIX HIVE
• 1 x USB Type-C^® power connection cable
• 1 x Thermal pad for M.2
• 1 x ASUS Wi-Fi moving antennas
• 1 x Cable ties pack
• 1 x Rubber Package(s) for M.2
• 1 x Q-Latch package(s) for M.2
• 1 x ROG key chain
• 1 x ROG Strix stickers
• 1 x ROG Strix thank you card
• 1 x User guide

Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: 3 Year
