AXIS P3268-SLVE Network Camera

Marketing Information

Enclosed in a marine-grade, stainless steel casing, this robust and DNV-certified camera can withstand the corrosive effects of seawater and cleaning chemicals. Easy to clean and maintain, it's certified by NSF/ANSI to Standard 169 (Special Purpose Food Equipment and Devices) for use in food processing facilities. With Lightfinder 2.0, Forensic WDR, and OptimizedIR, it delivers excellent 4K image quality under any light conditions. And a deep learning processing unit offers improved processing and storage capabilities. Furthermore, it includes Axis Edge Vault, a hardware-based cybersecurity platform that guarantees the device's integrity and protects it from unauthorized access.

Specifications
Manufacturer: Axis Communications
Manufacturer Part Number: 02710001
Manufacturer Website Address: http://www.axis.com/uk
Brand Name: AXIS
Product Series: P32
Product Model: P3268-SLVE
Product Name: P3268-SLVE Network Camera
Product Type: Network Camera
Technical Information
Recording Formats: 4K
HD Recording: Yes
Night Vision: Yes
Night Vision Distance: 40 m
Night Vision Type: Infrared
Camera Iris: P-iris
Display & Graphics
Image Sensor Type: RGB CMOS
Image Sensor Size: 1/1.8"
Colour Supported: Colour
Field of View: Horizontal: 100°-53°, Vertical: 54°-30°
Effective Camera Resolution: 8 Megapixel
Video
Video Formats:

• H.264
• H.265
• Motion JPEG
• H.264B (MPEG-4 Part 10/AVC)
• H.264H (MPEG-4 Part 10/AVC)
• H.264M (MPEG-4 Part 10/AVC)
• H.265 (MPEG-H Part 2/HEVC) Main Profile

Maximum Video Resolution: 3840 x 2160
Maximum Frame Rate: 30 fps
Lens
Lens Type: Varifocal
Minimum Focal Length: 4.30 mm
Maximum Focal Length: 8.60 mm
Lens Included: Yes
Maximum Aperture: f/1.5
Optical Zoom: 2x
Exposure
Shortest Shutter Speed: 1/8500 Second
Longest Shutter Speed: 1/5 Second
Network & Communication
Connectivity Technology: Wired
Ethernet Technology: Fast Ethernet
Protocols:

• IPv4
• IPv6 USGv6
• ICMPv4/ICMPv6
• HTTP
• HTTP/2
• HTTPS
• TLS
• DiffServ (QoS)
• FTP
• SFTP
• CIFS/SMB
• SMTP
• mDNS (Bonjour)
• UPnP
• SNMPv1/v2c/v3 (MIB2)
• DNS/DNSv6
• DDNS
• NTP
• NTS
• RTSP
• RTCP
• RTP
• SRTP/RTSPS
• TCP
• UDP
• IGMPv1/v2/v3
• DHCPv4/v6
• ARP
• SSH
• SIP
• LLDP
• CDP
• MQTT v3.1.1
• Syslog
• ZeroConf

Remote Management: Yes
Storage
Storage Type: Memory Card
Interfaces/Ports
Network (RJ-45): Yes
Power Description
Maximum Power Consumption: 11.20 W
Power Source Type: PoE
Physical Characteristics
Form Factor: Dome
Durability:

• Impact Resistant
• Water Resistant
• Corrosion Resistant

Height: 112 mm
Diameter: 166 mm
Weight (Approximate): 1.76 kg
Environmental Conditions
Minimum Operating Temperature: -40°C
Maximum Operating Temperature: 50°C
Maximum Operating Humidity: 100%
Miscellaneous
Features:

• Day/Night
• Ingress Protection
• Video Content Analytics
• Human Detection
• Vehicle Detection
• Motion Detection
• HTTPS Encryption
• Tampering Alarm
• Tamper Detection
• Defog
• White Balance

Indoor/Outdoor: Outdoor
Impact Protection Rating: IK11
Ingress Protection Rating:

• IP66
• IP67
• IP6K9K

TAA Compliant: Yes
