D-Link 5-Port Multi-Gigabit Unmanaged Switch

Marketing Information

The DMS-105 5-Port Multi-Gigabit Unmanaged Switch is ideally suited for Small Office Home Office (SOHO) environments. With a durable design, silent operation, and plug-and-play functionality, the DMS-105 switch can be easily set up and be placed in almost any location where network connectivity is required. Support for IEEE 802.3az Energy-Efficient Ethernet (EEE), 802.1p Quality of Service (QoS), and multi-Gigabit Ethernet connection speeds provide advanced features in a compact package.

Integrated Networking

The DMS-105 switch uses auto-sensing ports, providing a small workgroup to flexibly connect Ethernet, Fast Ethernet, Gigabit and 2.5 Gigabit devices to create an integrated network. These ports detect the network s...peed via auto-negotiation allowing you to get the maximum speed possible for each device connected to your network.

Simplified Installation

All of the ports on the DMS-105 switch supports automatic MDI/MDIX crossover, eliminating the need for crossover cables. Each port can be plugged in directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables. In addition, the DMS-105 switch features multiple front, easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status

Specifications
Manufacturer: D-Link Systems, Inc
Manufacturer Part Number: DMS105B
Manufacturer Website Address: http://www.dlink.co.uk
Brand Name: D-Link
Product Model: DMS-105/B
Product Name: 5-Port Multi-Gigabit Unmanaged Switch
Product Type: Ethernet Switch
Technical Information
Features: Fanless
Interfaces/Ports
Total Number of Network Ports: 5
Port/Expansion Slot Details: 5 x 2.5 Gigabit Ethernet Network Port
Media & Performance
Media Type Supported: Twisted Pair
Ethernet Technology:

• 2.5 Gigabit Ethernet
• Gigabit Ethernet

Network Technology:

• 2.5GBase-T
• 10/100/1000Base-T

Network & Communication
Layer Supported: 2
Networking Standards:

• IEEE 802.1p
• IEEE 802.3az
• IEEE 802.3x
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3bz

Management & Protocols
Manageable: No
Power Description
Input Voltage: 12 V
Power Source: Power Adapter
Power Consumption: 4.92 W
Physical Characteristics
Product Material: Metal
Height: 28 mm
Width: 82 mm
Depth: 100.5 mm
Weight (Approximate): 238.6 g
Miscellaneous
Application/Usage: Network
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
