i-tec Docking Station

Marketing Information

A powerful office docking station supporting super-fast USB Gen 2 ports. Dock supports output to up to two external monitors in up to 4K high resolution. The dock can be used with virtually all notebooks as it supports connection to all common ports: USB 3.0, USB-C and Thunderbolt" 3/4, while supporting all common current operating systems. Plenty of USB ports (two USB-C support Gen 2 speeds of up to 10 Gbps), reliable and fast connection to the corporate network thanks to the integrated LAN port and support for installation behind the monitor all make this docking station the ideal companion for true professionals. Of course, it supports charging of your laptop or tablet, up to 100 W.

• Connect to 2 external monitors in resolut...ions up to 4K
• Power delivery: up to 100 W
• 2 DisplayPort and 2 HDMI ports available
• 4x USB 3.0 Gen 1 (5 Gbps) and 2x USB-C Gen 2 (10 Gbps) allow you to easily connect your USB devices and peripherals
• Gigabit Ethernet RJ-45 provides reliable, robust and high-speed internet connectivity with support for 10/100/1000 Mbps speeds
• Combo jack for audio and microphone
• Kensington lock provides anti-theft protection, especially in shared office environments or public areas
• Docking station power switch allows for maximum power savings
• Docking station supports a VESA mount for smart vertical installation behind a VESA-enabled monitor
• Supports Windows 10 / 11, macOS, Android 5 or later, Chrome OS R51 or later, Linux Ubuntu

If the docking station is connected via USB 3.0 port, charging is not supported.

Specifications
Manufacturer: i-tec Technologies s.r.o.
Manufacturer Part Number: CADUA4KDOCKPDL2UK
Manufacturer Website Address: http://www.i-tec.pro
Brand Name: i-tec
Product Name: Docking Station
Product Type: Docking Station
Technical Information
Connectivity Technology: Wired
Device Supported:

• Monitor
• Tablet
• Notebook

Number of Displays Supported: 2
Screen Mode Supported:

• 4K
• 5K

Supported Resolutions:

• 3840 x 2160
• 5120 x 2880

Maximum Data Transfer Rate: 1.25 GB/s
Network & Communication
Ethernet Technology: Gigabit Ethernet
Interfaces/Ports
Host Interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Total Number of USB Ports: 7
Number of USB 3.2 Gen 1 Type-A Ports: 4
Number of USB Type-A Ports: 4
Number of USB Type-C Ports: 3
USB Type-A: Yes
USB Type-C: Yes
USB Type-C Detail: 2 x USB-C 3.2 port Gen.2 with fast charging support (BC 1.2), 1 x USB-C port for connection to USB-C or USB-A devices
Network (RJ-45): Yes
Number of RJ-45 Ports: 1
Number of Network (RJ-45) Ports: 1
Number of DisplayPorts: 2
DisplayPort: Yes
Headphone/Microphone Combo Port: Yes
Number of HDMI Ports: 2
HDMI: Yes
USB Power Delivery: 100W
Software
Operating System Supported:

• Windows 10
• Windows 11
• Mac OS X
• Android 5.0 Lollipop
• Ubuntu 14.04
• Ubuntu 16.04
• Ubuntu 18.04
• Ubuntu 19.04
• Ubuntu 17.10
• Ubuntu 17.04
• ChromeOS

Power Description
Power Source Type: Power Adapter
Physical Characteristics
Color Family: Black
Product Color: Black
Height: 224 mm
Width: 88 mm
Depth: 27 mm
Weight (Approximate): 330 g
Miscellaneous
Package Contents:

• Docking Station
• USB-C Connection Cable and USB-C to USB 3.0 Adapter (100cm)
• Power Adapter (DC Cable 120cm, Power Cord 150cm)
• Manual

Kensington Security Slot: Yes
Warranty
Limited Warranty: 2 Year
