LINDY 3m DisplayPort 1.4 Extension Cable, Anthra Line

Marketing Information

• Professional choice DisplayPort 1.4 cable for commercial and high performance AV and IT installations
• Supports UHD resolutions up to 7680x4320@60Hz 4:2:2 8bit
• Robust PVC housing, gold plated connectors and contacts
• Triple shielded cable, corrosion resistant copper alloy 28AWG conductors
• DisplayPort 1.4 compliant: 3D, 8K, 32.4Gbps, 10 year warranty

From the Lines cable connectivity concept developed by Lindy, Anthra Line DisplayPort cables are the professional choice for high performance connections in commercial AV and IT installations.

Anthra Line DisplayPort cables are premium connections that feature triple shielded with 28AWG tinned copper conductors for performance... and corrosion resistance. High quality gold plated contacts and connectors maintain optimal signal integrity and maximum reliability.

UHD resolutions up to 7680x4320@60Hz 4:2:2 8bit, including stereoscopic 3D and HDCP are supported. DisplayPort 1.4 technology ensures compatibility with all DisplayPort enabled devices.

Anthra Line DisplayPort cables are available in lengths from 0.5m to 3m.

Specifications
Manufacturer: Lindy Electronics
Manufacturer Part Number: 36498
Manufacturer Website Address: http://www.lindy.com
Brand Name: LINDY
Product Line: Anthra Line
Product Name: 3m DisplayPort 1.4 Extension Cable, Anthra Line
Product Type: A/V Cable
Technical Information
Cable Type: DisplayPort
Cable Characteristic: Extension Cable
Cable Length: 3 m
Connector Type on First End: DisplayPort 1.4 Digital Audio/Video - Male
Connector on First End Details: 1 x DisplayPort 1.4 Digital Audio/Video - Male
Connector Type on Second End: DisplayPort 1.4 Digital Audio/Video - Female
Connector on Second End Details: 1 x DisplayPort 1.4 Digital Audio/Video - Female
Connector Plating: Gold
Contact Plating: Gold
Shielding: Yes
Device Supported: Audio/Video Device
American Wire Gauge: 28 AWG
Data Transfer Rate: 32.4 Gbit/s
Supported Resolution: 7680 x 4320
Features:

• Bendable
• Triple Shielded
• Corrosion Resistant
• Stereoscopic 3D Support
• HDCP

Physical Characteristics
Product Color: Black
Product Material:

• Acrylonitrile Butadiene Styrene (ABS)
• Polyvinyl Chloride (PVC)
• Copper Alloy

Contact Material: Copper Alloy
Shielding Material: Braided Aluminum Magnesium
Jacket Material: Polyvinyl Chloride (PVC)
Material Details: Conductor - Copper Alloy
Housing - Acrylonitrile Butadiene Styrene (ABS), Polyvinyl Chloride (PVC)


Warranty
Limited Warranty: 10 Year
