LINDY DST-Mini Duo, USB-C Laptop Mini Docking Station 2 x 4K HDMI

Marketing Information

The DST-Mini Duo is a high performance and versatile solution for connecting laptops, tablets or smartphones to a range of interfaces including 2 HDMI displays. Featuring all critical interfaces required for a modern workstation, this Mini Docking Station uses a single USB 3.2 Type C cable to connect up to two 4K displays simultaneously, while improving connectivity to other devices through Gigabit Ethernet and USB 3.2 / 3.1 SuperSpeed 10Gbps and 5Gbps ports.

This Laptop Docking Station enables the connection of an HDMI display to a laptop at resolutions of 8K 7680x4320 30Hz using DisplayPort Alternate Mode through the USB Type C port. It also supports video resolutions of 4K 120Hz, making it the ideal tool for high resolution video ...editing or game streaming. It features three USB 3.2 Gen 2 Type C and A ports providing 10Gbps high data transfer speeds as well as three 5Gbps USB Type A ports.

This Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop. A power supply is not included. The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.

Specifications
Manufacturer: Lindy Electronics
Manufacturer Part Number: 43373
Manufacturer Website Address: http://www.lindy.com
Brand Name: LINDY
Product Line: DST-Mini Duo
Product Name: DST-Mini Duo, USB-C Laptop Mini Docking Station 2 x 4K HDMI
Product Type: Docking Station
Technical Information
Connectivity Technology: Wired
Device Supported:

• Smartphone
• Tablet PC
• Notebook
• Desktop PC

Memory Card Reader: Yes
Memory Card Supported: microSD
Features: Power Delivery Pass-through
Number of Displays Supported: 2
Screen Mode Supported:

• 4K
• 8K

Supported Resolutions:

• 3840 x 2160
• 7680 x 4320

Maximum Data Transfer Rate: 1.25 GB/s
Network & Communication
Ethernet Technology: Gigabit Ethernet
Interfaces/Ports
Host Interface: USB Type C
Total Number of USB Ports: 8
Number of USB 3.0 Ports: 5
Number of USB Type-A Ports: 5
Number of USB Type-C Ports: 3
USB Type-A: Yes
USB Type-C: Yes
USB Type-C Detail: 1 x USB Type C (Male), 1 x USB Type C (Female), 1 x USB Type C (Female) PD port
Network (RJ-45): Yes
Number of RJ-45 Ports: 1
Number of Network (RJ-45) Ports: 1
Number of HDMI Ports: 2
HDMI: Yes
HDMI Version: 2.1
USB Power Delivery: 100W
Software
Operating System Supported:

• Windows
• Android
• Linux
• macOS
• ChromeOS

Physical Characteristics
Color Family: Grey
Product Color: Dark Grey
Height: 21.7 mm
Width: 165 mm
Depth: 49 mm
Weight (Approximate): 160 g
Miscellaneous
Package Contents:

• DST-Mini Duo, USB-C Laptop Mini Docking Station 2 x 4K HDMI
• Lindy Manual

Compatibility:

USB Type C or Thunderbolt 3/4 equipped computers

Environmental Compliance:

• Restriction of Hazardous Substances (RoHS)
• Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

Warranty
Limited Warranty: 2 Year
