LINDY 300m Fibre Optic HDMI 2.0 10.2G Extender

Marketing Information

• Extends HDMI signals at distances of up to 300m using a single fibre optic cable (not included)
• Supports resolutions up to Ultra HD 4K 60Hz 4:2:0 8 bit, including 1080p 3D
• 10.2 Gbps Total Bandwidth over Single 2-core Fibre Optic Cable Link
• Supports lossless HDMI audio formats including Dolby True HD and DTS-HD
• 2 year warranty

Easy to set up and install the compact, simple to use Lindy LC Fibre Optic HDMI Extender is the most cost effective, high quality solution on the market for sending HDMI signals over incredible distances. USB powered it sends HDMI signals without compression or any degradation up to 300m over standard OM3 LC duplex multimode (50/125µm) fibre cable (not incl...uded).

The extender system comprises of two modules, a transmitter and a receiver, which are connected directly to both the HDMI source and display. The modules are then connected together using a single, standard 'off the shelf' LC fibre optic cable (not included).

Please note: This extender supports DisplayPort 1.1 up to 4K30 / 3840x2160 @ 30Hz using the Lindy adapters No.41068 (at the source) and No.38146 (at the monitor).

Specifications
Manufacturer: Lindy Electronics
Manufacturer Part Number: 38170
Manufacturer Website Address: http://www.lindy.com
Brand Name: LINDY
Product Name: 300m Fibre Optic HDMI 2.0 10.2G Extender
Product Type: Video Extender Transmitter/Receiver
Technical Information
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 300 m
Video
Graphics Modes: 4K
Maximum Video Resolution: 3840 x 2160
Interfaces/Ports
HDMI In: Yes
HDMI Out: Yes
USB: Yes
Number of USB Ports: 2
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
Physical Characteristics
Product Color: Black
Transmitter Height: 12 mm
Transmitter Width: 75 mm
Transmitter Depth: 20 mm
Receiver Height: 12 mm
Receiver Width: 75 mm
Receiver Depth: 20 mm
Transmitter Weight (Approximate): 48 g
Receiver Weight (Approximate): 48 g
Miscellaneous
Package Contents:

• Transmitter Unit
• Receiver Unit
• 2 x USB A/Micro-B Cable
• Lindy Manual

Warranty
Limited Warranty: 2 Year
