Meraki Wi-Fi 6 (802.11ax) With Multigigabit Ethernet

Marketing Information

Ideal use cases

• Performance-critical wireless LANs
• High-density environments

Hardware features

• 4 radios: 2.4 GHz, 5 GHz, dual-band
• Embedded WIDS/WIPS and Bluetooth
• 4-stream UL/DL MU-MIMO 802.11ax (5GHz), 2-stream UL/DL MU-MIMO 802.11ax (2.4GHz)
• 1 × 2.5 Gbps Multigigabit Ethernet port
• PoE: 802.3af/at
• AC adapter available

Cloud management

• Network-wide visibility and control
• Self-provisioning for rapid deployment
• Automatic reporting
• Seamless firmware updates

Enterprise security

• 802.1X and native Active Directory integration
• Air Ma...rshal: Real-time WIPS with forensics
• Stateful Layer 3-7 firewall
• Identity-based group policies
• Built-in antivirus scan (NAC)
• Built-in Umbrella DNS Security
• Adaptive Policy automated segmentation

Guest access

• 1-click secure guest access
• Guest isolation firewall
• Customizable splash pages
• Integrated Facebook login

RF optimization

• Dual-concurrent radios with MU-MIMO support
• Radios optimized for rate-vs-range performance
• Dedicated security and RF management radio
• Built-in real-time RF spectrum view
• Cloud-based automatic RF optimization

Layer 7 traffic shaping

• Classifies hundreds of applications
• Create per-application bandwidth limits
• Prioritize productivity apps
• Restrict or block recreational traffic

Presence location analytics

• Measure visitor capture rate, visit length, and repeat visit rate
• Measure visitor trends over time and compare performance across locations

Device management

• Create device-specific firewall rules
• Monitor and track device inventory
• Deploy applications and enforce security settings

Specifications
Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: MR44-HW
Manufacturer Website Address: http://www.cisco.com
Brand Name: Meraki
Product Model: MR44
Product Name: Wi-Fi 6 (802.11ax) With Multigigabit Ethernet
Product Type: Wireless Access Point
Technical Information
Wireless LAN Standard: 802.11ax
Frequency Band:

• 2.40 GHz
• 5 GHz

Wireless Transmission Speed: 2.93 Gbit/s
MIMO Technology: Yes
Beamforming Technology: Yes
Data Encryption: Yes
Encryption Standard:

• WEP
• WPA
• WPA2-PSK
• WPA2-ENT
• WPA3-PSK
• WPA3-ENT
• TKIP
• AES

Interfaces/Ports
Ethernet Technology: 2.5 Gigabit Ethernet
Number of Network (RJ-45) Ports: 1
Physical Characteristics
Form Factor:

• Desktop
• Ceiling Mountable
• Wall Mountable

Height: 44.3 mm
Width: 306 mm
Depth: 128.4 mm
Weight (Approximate): 739.1 g
