Netgear Smart GS724TP Ethernet Switch

Marketing Information
As a leading provider of network equipment for SMBs, NETGEAR® understands the importance of providing great choice of PoE port counts and power budgets that can adapt to the business's needs, whether in the hospitality, catering, education or retail domains.
The GS724TPv2 and GS724TPP 24-Port Gigabit Switch with PoE+ and 2 SFP Ports join the NETGEAR Standalone Smart Managed Pro Switches family, adding full 24 port PoE+ support for deployment of modern high-power PoE devices. Cautious spender organizations can now deploy denser PoE+ devices connected to a costeffective switch, with a reasonable PoE power budget of 190W (GS724TPv2) or 380W (GS724TPP).
NETGEAR Smart Managed Pro Switches offer powerful Layer 2 features, great PoE ...functionality, and enhanced performance and usability. These switches are the ideal solution even for the most advanced small and medium organizations looking for the best combination of features, performance, and value: they are purposely designed for converged networks where voice, video, data are all carried on a single network platform. Temperature- and load-based fan-speed control combines accurate monitoring with minimized system acoustic noise: the GS724TPv2 and GS724TPP support quiet rack mounting operation with a maximum of 32.4 dBA (GS724TPv2) and 35.0 dBA (GS724TPP) even at full power and 25°C (77°F) ambient.
To empower the PoE applications, NETGEAR Insight Remote/Cloud Management is added to these two new switch models as an optional management mode. By activating the NETGEAR Insight Cloud management, the users will enable management features allowing businesses simpler configuration and deployment from anywhere using the NETGEAR Insight app from mobile devices or the Insight Cloud Portal from any device with a web browser.
Specifications
Manufacturer: Netgear, Inc
Manufacturer Part Number: GS724TP300EUS
Manufacturer Website Address: http://www.netgear.co.uk
Brand Name: Netgear
Product Line: Smart
Product Model: GS724TP
Product Name: Smart GS724TP Ethernet Switch
Product Type: Ethernet Switch
Technical Information
Features:

• VLAN Segmentation
• Access Control List

Interfaces/Ports
Total Number of Network Ports: 24
Uplink Port: Yes
Modular: Yes
Network (RJ-45): Yes
Port/Expansion Slot Details:

• 24 x Gigabit Ethernet PoE+
• 2 x Gigabit Ethernet Expansion Slot

Media & Performance
Media Type Supported:

• Twisted Pair
• Optical Fiber

Ethernet Technology: Gigabit Ethernet
Network Technology:

• 10/100/1000Base-T
• 1000Base-X

I/O Expansions
Total Number of Expansion Slots: 2
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 2
Network & Communication
Layer Supported: 4
Networking Standards:

• IEEE 802.1x
• IEEE 802.1p
• IEEE 802.3az
• IEEE 802.3
• IEEE 802.11ac
• IEEE 802.3at
• IEEE 802.3af
• IEEE 802.1Q
• IEEE 802.3ad
• IEEE 802.1D
• IEEE 802.1w
• IEEE 802.1s

Management & Protocols
Manageable: Yes
Switch Management Type: Smart Managed
Power Description
PoE (RJ-45) Port: Yes
PoE Budget: 380 W
Power Source: Power Supply
Power Consumption: 228.53 W
Physical Characteristics
Form Factor:

• Rack-mountable
• Desktop

Height: 43 mm
Width: 440 mm
Depth: 204 mm
Weight (Approximate): 3.15 kg
Miscellaneous
Application/Usage:

• VoIP Phone
• Security Camera
• Wireless Access Point
• Network

Energy Efficiency Compliance: Energy-related Products Directive (ErP)
Environmental Compliance:

• Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
• Restriction of Hazardous Substances (RoHS)
• Waste Electrical and Electronic Equipment Directive (WEEE)
