Star Micronics TSP143IV UE GRY E+U Direct Thermal Printer

Marketing Information

TSP100IV - Next Generation Printing

The new TSP100IV brings a unique new design for a truly revolutionary product. The quality and reliability of the popular TSP100 series has been fused with enhanced connectivity and specialist printing features for the very latest in point of sale and omni-channel commerce. For ever-changing retail and hospitality environments, the TSP100IV has every angle covered!

Smaller, Sharper, Better Connected

Super compact at 20% smaller than TSP100III models with an internal power supply the TSP100IV saves valuable counter space and can operate horizontally or vertically. Integral wall mounting is included.

Developed for Tablet and Cloud POS

The TSP100IV f...eatures enhanced connectivity with Ethernet LAN and USB-C ports for Windows, Linux and MacOS devices as well as USB-A for connecting Android tablets and mobile devices. With Android Open Accessory (AOA) support, compatible Android tablets and mobile devices or accessories such as scanner or display can communicate and charge directly via USB. Wireless LAN connectivity is also available with Star's optional MCW10 Wireless LAN adapter.

Star's CloudPRNT technology is also integrated for printing directly from web based applications, ideal for retail Click & Collect orders or restaurant orders direct to the kitchen without the need for a local tablet or POS system.

Star Micronics Cloud Services is also included offering device monitoring and many other services.

Plug & Play

The Star TSP100IV has exceptionally easy "plug and play" installation with Star's new intuitive Quick Set-up Utility, making it simple to incorporate into existing point of sale systems. It's also compatible with previous TSP100 models.

Required Set-up accessories are included at purchase including Power cable, interface cables and 58mm paper guide as well Star's 4 year warranty as standard.

Specifications
Manufacturer: Star Micronics, Inc
Manufacturer Part Number: 39473090
Manufacturer Website Address: http://www.starmicronics.com
Brand Name: Star Micronics
Product Series: TSP143IV
Product Model: TSP143IV UE GRY E+U
Product Name: TSP143IV UE GRY E+U Direct Thermal Printer
Product Type: Direct Thermal Printer
Technical Information
Recommended Use: Receipt Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 250 mm/s
Maximum Print Resolution (dpi): 203
Maximum Print Width: 72 mm (2.83")
Application/Usage: Desktop
Features: Compact
Wireless Print Technology: Star CloudPRNT
Mean Cycles Between Failures (MCBF): 60000000
Column Capacity: 48 / 64 col.
Installation: Horizontal/Vertical
Connectivity Technology: Wired & Wireless
Optional Connectivity: Wireless LAN
Print Technology: Direct Thermal
Interfaces/Ports
USB Host: Yes
USB: Yes
Network & Communication
Ethernet: Yes
Ethernet Technology: Ethernet
Cutter
Cutter: Yes
Cutting Method: Automatic
Cutter Type: Guillotine
Cut Type: Partial Cut
Cutter Life: 2000000 Cuts
Media Types & Handling
Media Type: Receipt
Media Sensor:

• Paper End Sensor
• Cover Open Sensor

Media Thickness: 85 µm
Maximum Label Width: 80 mm
Software
Operating System Supported:

Windows Drivers, OPOS Driver, JavaPOS Drivers (Windows/Mac/Linux), CUPS Drivers (Mac/Linux), StarXpand SDK (React Native, iOS, Android)

Power Description
Power Source: Power Adapter
Physical Characteristics
Form Factor: Wall Mount
Color Family: Grey
Product Color: Grey
Height: 123 mm
Width: 140 mm
Depth: 169 mm
Weight (Approximate): 1.30 kg
Miscellaneous
Power Cable Localization:

• UK
• EU

Cables Included:

• AC
• USB

Platform Supported:

• PC
• Android
• iOS
• SPARC

Energy Star: Yes
