Star Micronics TSP143IV UEWB GY E+U Direct Thermal Printer

Marketing Information

TSP100IV - Next Generation Printing

The new TSP100IV brings a unique new design for a truly revolutionary product. The quality and reliability of the popular TSP100 series has been fused with enhanced connectivity and specialist printing features for the very latest in point of sale and omni-channel commerce. For ever-changing retail and hospitality environments, the TSP100IV has every angle covered!

Cloud Ready

All models are web and cloud ready with Star's popular CloudPRNT Technology, offering simple receipt and order printing for online stores and e-commerce platforms.

Future Proof Design

Unique compact design with every connectivity option you could need! Take the worry out of fu...ture-proofing your business.

Star Reliability

Along with Star's quality build, the TSP100IV comes with a 4 year warranty including print head and cutter for complete peace of mind.

Save space, save paper!

Super compact at 20% smaller than TSP100III models with an internal power supply, the TSP100IV saves valuable counter space and can operate horizontally, vertically or wall mounted, printing 80mm or 58mm wide receipts at a speedy 250mm/s. Auto-reduction and thin paper support allow significant paper savings.

Connect to WiFi in less than 1 minute

The new TSP143IV X4 delivers exceptionally simple WLAN and Bluetooth setup designed to simplify wireless connectivity 'out-of-the-box'. As a result, users can quickly connect via an auto-generated QR code or via the Star Quick Set Up Utility and be online within less than a minute.

Print in-store receipts and online orders

The TSP100IV features enhanced connectivity for POS, mPOS and Cloud-based applications. With wired and wireless connectivity as well as direct USB sync and charge with Android devices and Star CloudPRNT Next technology , the TSP100IV can handle in-store receipting and on-line orders with ease.

Product Features

• New generation POS receipt printers with enhanced connectivity
• Compact design with internal power supply. Horizontal, vertical or wall-mount operation.
• 250mm/s print speed with high quality guillotine cutter
• 80mm paper width (58mm paper with included paper guide) and 49µm thin paper support
• Ethernet LAN and USB-C / USB-A connectivity. Additional Bluetooth and Dual Band WLAN with TSP143IV X4 model
• Direct sync & charge with compatible Android tablets and mobile devices or control of USB peripherals (scanner, display etc.) via USB-A.
• Integrated Star CloudPRNT Next technology for online receipt and order printing
• Simple WLAN set-up with auto-generated QR code or Star Quick Set-Up Utility
• All set-up accessories included in the box at purchase: Power cable, USB cable and paper guide

Specifications
Manufacturer: Star Micronics, Inc
Manufacturer Part Number: 39473890
Manufacturer Website Address: http://www.starmicronics.com
Brand Name: Star Micronics
Product Series: TSP100
Product Model: TSP143IV UEWB GY E+U
Product Name: TSP143IV UEWB GY E+U Direct Thermal Printer
Product Type: Direct Thermal Printer
Technical Information
Recommended Use: Receipt Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 250 mm/s
Maximum Print Resolution (dpi): 203
Maximum Print Width: 72 mm (2.83")
Application/Usage:

• Desktop
• POS System

Features: Compact
Wireless Print Technology: Star CloudPRNT
Mean Cycles Between Failures (MCBF): 60000000
Column Capacity: 48 / 64 col.
Installation: Horizontal/Vertical
Connectivity Technology: Wired & Wireless
Print Technology: Direct Thermal
Interfaces/Ports
USB Host: Yes
USB: Yes
USB Standard: USB Type C
Network & Communication
Ethernet: Yes
Ethernet Technology: Ethernet
Bluetooth: Yes
Wireless LAN: Yes
Cutter
Cutter: Yes
Cutting Method: Automatic
Cutter Type: Guillotine
Cut Type: Partial Cut
Cutter Life: 2000000 Cuts
Media Types & Handling
Media Type: Receipt
Media Sensor:

• Paper End Sensor
• Cover Open Sensor

Media Thickness: 80 µm
Maximum Roll Diameter: 83 mm
Maximum Label Width: 80 mm
Software
Operating System Supported:

Windows Drivers, OPOS Driver, JavaPOS Drivers (Windows/Mac/Linux), CUPS Drivers (Mac/Linux), StarXpand SDK (React Native, iOS, Android)

Power Description
Power Source: AC Supply
Maximum Power Consumption: 43 W
Standby Power Consumption: 3.50 W
Physical Characteristics
Form Factor: Wall Mount
Color Family: Grey
Product Color: Grey
Height: 123 mm
Width: 140 mm
Depth: 169 mm
Weight (Approximate): 1.30 kg
Miscellaneous
Power Cable Localization:

• UK
• EU

Package Contents:

• TSP143IV UEWB GY E+U Direct Thermal Printer
• Power Cable
• USB Cable (USB-C to USB-A)
• 58mm Paper Guide

Cables Included:

• AC
• USB

Platform Supported:

• PC
• Android
• iOS
• SPARC

Energy Star: Yes
Warranty
Limited Warranty: 4 Year
