StarTech.com Coaxial Data Transfer Cable

Marketing Information

This 3ft (1m) USB4 Cable connects to USB Type-C (USB 3.2), Thunderbolt 4/3, and PCIe-enabled devices, delivering up to 40Gbps, 4K/8K video, and 100W charging.

Establish Fast and Stable Power/Data Connections

This USB4 Type-C cable is USB-IF certified for guaranteed USB-C compatibility. It reliably delivers consistent transfer rates and up to 100W PD output. It is ideal for 40Gbps data transfer to external USB-C-enabled external storage devices or as a single-cable connection from a USB-C dock to a laptop.

This cable has undergone rigorous USB-IF compliance testing to meet USB4 specifications. This includes electrical and mechanical standards which ensures a reliable, high-quality cable for USB-C devices.

Experience ...8K Video with DisplayPort 1.4 Alt Mode

The USB4 cable supports up to 8K 60Hz video over DisplayPort 1.4 Alt Mode with DSC, HDR, and HBR3, and is compatible with dual 4K 60Hz and lower resolutions.

Power a USB-C Laptop

Power and charge a USB-C laptop, such as Apple MacBook, Lenovo ThinkPad, or Microsoft Surface with up to 100W output over USB Power Delivery 3.0. Connect the USB4 cable from a laptop to a USB-C wall charger or docking station.

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: CC1M40GUSBCABLE
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: Coaxial Data Transfer Cable
Packaged Quantity: 1
Product Type: Data Transfer Cable
Technical Information
Cable Type: Coaxial
Cable Length: 91.44 cm
Connector Type on First End: USB4 Thunderbolt 4 Type C - Male
Connector Gender on First End: Male
Connector on First End Details: 1 x USB4 Type C - Male
Connector Type on Second End: USB4 Thunderbolt 4 Type C - Male
Connector Gender on Second End: Male
Connector on Second End Details: 1 x USB4 Type C - Male
Connector Plating: Nickel
Shielding: Yes
Device Supported:

• Storage Device
• Dock
• Notebook
• MacBook
• Wall Charger
• Docking Station
• Monitor
• USB Device

American Wire Gauge: 34 AWG
Data Transfer Rate: 40 Gbit/s
Supported Resolution: 7680 x 4320
Features:

• Passive
• EMI Protection
• DisplayPort Alternate (ALT) Mode
• Charging
• Display Stream Compression (DSC)
• HDR Support
• Power Delivery 3.0
• E-marker Chip
• Strain Relief
• Halogen Free

Physical Characteristics
Color Family: Black
Product Color: Black
Shielding Material: Mylar
Jacket Material: Thermoplastic Elastomer (TPE)
Miscellaneous
Compatibility:

Apple - MacBook

Warranty
Limited Warranty: 2 Year
