StarTech.com HDMI Video Switch

Marketing Information

This 4-Port HDMI Video Switch enables four HDMI sources to connect to a single HDMI input on a display.

8K 60Hz Resolution

The HDMI Switcher supports resolutions of up to 8K 60Hz. In addition, it supports lower resolutions at higher refresh rates, such as 4K 144Hz, 4K 120Hz, and 1080p 240Hz.

This Video Switch is HDMI 2.1 complaint and supports features such as Variable Refresh Rate (VRR), Auto Low-Latency Mode (ALLM), and Consumer Electronics Control (CEC). It is backwards compatible with HDMI 2.0 (and lower) devices.

Automatic or Manual Operation

The 8K Video Switch features three options for selecting the source device. Automatic mode detects and selects the most recently activated source ...device or it will revert to the last active source device. Manual mode selects the desired port, using the push buttons, or with the included remote control (batteries not included). The remote control can enable or disable the automatic switching mode and it can disable the IR functionality.

Flexible Installation Options

Use the included USB wall charger and 2.5ft (78cm) USB Micro-B cable to power the unit. If a wall outlet is unavailable, the 8K Switch can be powered through a 5V 1A USB port as well.

The included mounting kit and rubber feet enable versatile installation options. The metal housing enhances durability, making it suitable for installation and use in a variety of environments.

This product is backed for 2-years by StarTech.com, including free 24/5 multi-lingual technical assistance.

More from the Manufacturer

More from the Manufacturer

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: 4PORT-8K-HDMI-SWITCH
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: HDMI Video Switch
Packaged Quantity: 1
Product Type: Video Switchbox
Technical Information
Connectivity Technology: Cable
Number of Input Devices Supported: 4
Device Supported: Display
Number of Displays Supported: 1
Video
Graphics Modes: 8K
Maximum Video Resolution: 7680 x 4320
Scan Format: 1080p
Interfaces/Ports
HDMI In: Yes
HDMI Out: Yes
USB: Yes
Number of USB Ports: 1
Number of HDMI Inputs: 4
Number of HDMI Outputs: 1
Media & Performance
Maximum Operating Distance: 5 m
Physical Characteristics
Form Factor: Wall Mountable
Height: 14 mm
Width: 61 mm
Depth: 136 mm
Weight (Approximate): 150 g
