StarTech.com KVM Switchbox

Marketing Information

Share and switch between two USB-A and DisplayPort-enabled computers, using this DisplayPort KVM Switch. Share an 8K 60Hz DisplayPort monitor, a keyboard and mouse, two USB 5Gbps devices, and two additional USB 2.0 devices.

High-Resolution 8K 60Hz Video

This KVM supports resolutions up to 8K 60Hz or 4K 144Hz/120Hz. Daisy chain additional monitors via MST pass-through. The KVM supports ultrawide resolutions of up to 5120x1440 at 60Hz. Ideal for applications such as CAD/CAM, video editing, and content creation. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.

Customizable Switching

This Universal KVM Switch provides various switching options, inc...luding hotkey or push-button switching. Hotkeys allow for independent switching of audio and video, enabling audio playback from one computer while controlling the other. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.

Universal Compatibility

The TAA-Compliant KVM Switch offers universal compatibility, working with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.

Reliable Performance

The durable metal housing helps prevent Electro-magnetic Interference (EMI). Overcurrent Protection (OCP) ensures peripherals don't overdraw power, reducing the occurrence of device dropouts or shutdowns.

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: D86A24PORT8KKVM
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: KVM Switchbox
Packaged Quantity: 1
Product Type: KVM Switchbox
Technical Information
Number of Computers Supported: 4
Number of Local Users Supported: 1
Maximum Data Transfer Rate: 640 MB/s
Features: LED Indicator
Video
Graphic Mode: 8K
Maximum Video Resolution: 7680 x 4320
Interfaces/Ports
USB: Yes
USB Standard:

• USB 3.2
• USB 2.0

USB 2.0: Yes
DisplayPort: Yes
Number of USB Ports: 10
Number of DisplayPorts: 5
Environmental Conditions
Minimum Operating Temperature: 0°C
Maximum Operating Temperature: 40°C
Power Description
Input Voltage Range: 100 - 240 AC
Power Plug Type: Type M
Physical Characteristics
Height: 43.2 mm
Width: 129.5 mm
Depth: 221 mm
Weight (Approximate): 1.04 kg
Miscellaneous
TAA Compliant: Yes
