StarTech.com KVM Switchbox

Marketing Information

This DisplayPort KVM Switch enables users to switch between two desktops equipped with USB-A and DisplayPort. It facilitates sharing a 4K 60Hz DisplayPort monitor, a keyboard, mouse, two USB 5Gbps devices, a stereo audio output device, and four USB 2.0 devices.

High-Resolution 4K 60Hz Video

This KVM supports resolutions up to 4K 60Hz, making it ideal for applications such as CAD/CAM, video editing, and content creation. In addition, its support for High Dynamic Range (HDR) enhances contrast, brightness, color, and overall vibrancy.

Customizable Switching

This universal KVM switch offers hotkey and push-button switching. Hotkeys allow independent switching of audio and video, enabling audio playback fro...m one computer while controlling another. An audible buzzer confirms hotkey inputs, and LEDs provide visual status feedback for the selected host.

Universal Compatibility

The TAA-compliant KVM Switch offers universal compatibility and works with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.

Reliable Performance

The rugged metal case helps prevent electromagnetic interference (EMI). 8kV Air/6kV Contact ESD protection enhances the reliability and longevity of the KVM. The included set of rubber feet protect the work surface from scratches and keep KVM in place during operation.

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: P4AD122-KVM-SWITCH
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: KVM Switchbox
Packaged Quantity: 1
Product Type: KVM Switchbox
Technical Information
KVM Technology: Digital & Analog
Number of Computers Supported: 4
Device Type: Desktop KVM
Maximum Data Transfer Rate: 640 MB/s
Features: LED Indicator
Video
Graphic Mode: 4K
Maximum Video Resolution: 4096 x 2160
Interfaces/Ports
USB: Yes
USB Standard:

• USB 3.2
• USB 2.0

USB 2.0: Yes
DisplayPort: Yes
Number of USB Ports: 6
Number of DisplayPorts: 5
Environmental Conditions
Minimum Operating Temperature: 0°C
Maximum Operating Temperature: 40°C
Power Description
Frequency: 60 Hz
Power Plug Type: Type M
Physical Characteristics
Form Factor: Desktop
Height: 43.2 mm
Width: 129.5 mm
Length: 220.98 mm
Weight (Approximate): 1.04 kg
Miscellaneous
TAA Compliant: Yes
