StarTech.com Fiber Optic Duplex Patch Network Cable

Marketing Information

LC/UPC to LC/UPC OM4 Multimode Switchable Fiber Optic Cable enables 40/100G network connections. The retractable strain-relief housings enable toolless in-field polarity swapping. Color-coded LC-Duplex connectors ensure error-free polarity configuration.

Engineered for Optimal Performance

Precision-manufactured ceramic ferrules ensure accurate fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics. The Laser-Optimized Multi-Mode Fiber (LOMMF) OM4 fiber patch cable is ideal for 850nm and 1300nm Vertical-Cavity Surface-Emitting Laser (VCSEL) and LED sources....

Compatibility

This multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40G networks, ensuring a reliable connection in legacy fiber environments.

LSZH Cable Jacket

Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.

Each OM4 fiber cable is also individually tested for insertion loss performance that meets or exceeds the TIA/EIA-568 industry standard, for guaranteed compatibility and 100% reliability.

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: 450FBLCLC5SW
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: Fiber Optic Duplex Patch Network Cable
Packaged Quantity: 1
Product Type: Network Cable
Technical Information
Cable Type: Fibre Optic
Cable Characteristic: Patch Cable
Fiber Optic Mode: Multi-mode
Fiber Type: Duplex
Fiber Category: OM4
Cable Length: 5 m
Connector Type on First End: LC/UPC Network - Male
Connector Gender on First End: Male
Connector on First End Details: 2 x LC/UPC Network - Male
Connector Type on Second End: LC/UPC Network - Male
Connector Gender on Second End: Male
Jacket Type: LSZH
Device Supported:

• Network Device
• Switch
• Server
• Module

Data Transfer Rate: 100 Gbit/s
Features:

• Bendable
• UPC Polished Connector
• Strain Relief
• Flame Retardant

Physical Characteristics
Product Color: Aqua
