StarTech.com Fiber Optic Duplex Patch Network Cable

Marketing Information

OM5 LC to LC Multimode Duplex Fiber Optic Patch cable facilitates connectivity across 40G and 100G networks. It supports SWDM (Shortwave Wavelength Division Multiplexing) across an extended wavelength range of 850-953nm VCSEL, enhancing signal quality and performance capacity over OM4.

Engineered for Optimal Performance

Precision-manufactured ceramic ferrules ensure correct fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics over older PC polishing techniques. The Laser-Optimized Multi-Mode Fiber (LOMMF) OM5 fiber patch cable is ideal for 850-953 nm Verti...cal-Cavity Surface-Emitting Laser (VCSEL) and 1300 nm LED sources.

Compatibility

This multimode 50/125µm fiber optic patch cord is backward compatible with OM4 and OM3 10G networks, ensuring a reliable connection in legacy fiber environments.

LSZH Cable Jacket

Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, the OM5 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.

Each OM5 fiber cable is also individually tested for insertion loss performance that meets or exceeds the TIA/EIA-568 industry standard, for guaranteed compatibility and 100% reliability.

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: LCLCL5MOM5FIBER
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: Fiber Optic Duplex Patch Network Cable
Packaged Quantity: 1
Product Type: Network Cable
Technical Information
Cable Type: Fibre Optic
Cable Characteristic: Patch Cable
Fiber Optic Mode: Multi-mode
Fiber Type: Duplex
Fiber Category: OM5
Cable Length: 5 m
Connector Type on First End: LC/UPC Network - Male
Connector Gender on First End: Male
Connector on First End Details: 2 x LC/UPC Network - Male
Connector Type on Second End: LC/UPC Network - Male
Connector Gender on Second End: Male
Connector on Second End Details: 2 x LC/UPC Network - Male
Jacket Type: LSZH
Device Supported:

• Network Device
• Switch
• Server

Data Transfer Rate: 100 Gbit/s
Features:

• Zip Cord
• Bend Insensitive
• Bendable
• UPC Polished Connector
• Flame Retardant

Physical Characteristics
Product Color: Green
Warranty
Limited Warranty: Lifetime
