StarTech.com 2-Port PCIe 10GBase-T / NBASE-T Ethernet Network Card - with Intel X550 Chip

Marketing Information
This Thunderbolt™3 to 10GbE NIC lets you connect your Thunderbolt 3 enabled device to a 10 Gigabit Ethernet network. This adapter combines the StarTech.com Thunderbolt 3 PCIe Expansion Chassis (TB31PCIEX16) and the 2-port PCI Express 10G NIC (ST10GPEXNDPI), giving you one DisplayPort output, one additional Thunderbolt 3 port and two 10GbE ports.

Reliable, high-performance and versatile multimode connectivity

This 10G network card utilizes the Intel® X550 chipset with Intel® Virtualization Technology for connectivity, delivering the power, performance and enhanced capabilities you need for dependable network connections.

Install and assemble with ease

Requiring only a Phillips type screwdrive...r, you can assemble this Thunderbolt 3 to 10GbE NIC chassis in minutes. It connects easily through a single Thunderbolt 3 port on your computer.

Change up your chassis

The Thunderbolt 3 chassis not only pairs well with the 10GbE NIC -- the card can be swapped for other PCIe cards to help support other functionality and performance. With the extra TB3 port and DP output built into the chassis, you will always have the ability to hook up extended displays to multitask effortlessly.

The TB31PCIEX16 and ST10GPEXNDPI are backed by a StarTech.com 2-year warranty.

More from the Manufacturer

More from the Manufacturer

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: ST10GPEXNDPI
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: 2-Port PCIe 10GBase-T / NBASE-T Ethernet Network Card - with Intel X550 Chip
Packaged Quantity: 1
Product Type: 10Gigabit Ethernet Card
Technical Information
Chipset Manufacturer: Intel
Chipset Model: X550AT
Interfaces/Ports
Host Interface: PCI Express 3.0 x4
Total Number of Ports: 2
Number of Network (RJ-45) Ports: 2
Media & Performance
Media Type Supported: Twisted Pair
Network & Communication
Network Technology: 10GBase-T
Physical Characteristics
Color Family: Black
Product Color: Black
Form Factor: Plug-in Card
Height: 81.3 mm
Width: 142.2 mm
Depth: 279.4 mm
Weight (Approximate): 1.63 kg
Miscellaneous
System Requirements:

• Windows® 7, 8, 8.1, 10
• Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
• (Windows Drivers are supported in 64-bit only)
• Linux 3.x to 4.11 LTS Versions only
