StarTech.com M.2 NVMe/SATA Duplicator Dock

Marketing Information

Perform bidirectional cloning between M.2 NVMe and 2.5/3.5" SATA SSDs/HDDs without a computer, using this M.2 NVMe to SATA Drive Duplicator. The standalone sector-by-sector duplication supports SATA III (6Gbps) and works with any file format.

Standalone M.2 NVMe to SATA Cloner Dock

Clone an M.2 NVMe drive to a 2.5"/3.5" SATA SSD/HDD or vice versa. This solution is ideal for hardware upgrades, system imaging, or routine maintenance. The Duplicator Dock supports 2240, 2260, and 2280 M.2 NVMe sizes and fits all standard SATA drives, seamlessly combining both legacy and modern storage solutions.

External Drive Access over USB-C

The USB 3.2 Gen 2 (10Gbps) host connection provides externa...l access to both M.2 NVMe and SATA drives, facilitating data transfer between systems without the need to install the drives internally.

Compact Form Factor

The Standalone M.2 NVMe to 2.5/3.5in SATA Cloner is portable and minimizes desk space usage. It enables instant data backup, and is ideal for IT Professionals when troubleshooting on-site, with the ability to re-image and re-deploy M.2 NVMe and SATA SSDs/HDDs without the need for a dedicated cloning station.

The SSD Cloner Dock features a top-loading design to promote passive airflow for consistent temperatures during peak performance. The Standalone Duplicator supports 4Kn sector size, TRIM, SMART, and UASP. Please note that the target disk must be equal to or larger than the source disk.

Applications

• Clone data from legacy SATA drives to M.2 NVMe
• Standalone Duplicator function is ideal for instant data backup, drive re-imaging, or deployments
• Enable quick drive access to M.2 NVMe and SATA SSDs/HDDs over a 10Gbps USB-C host connection

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: N2-M2-SSD-DUPLICATOR
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: M.2 NVMe/SATA Duplicator Dock
Product Type: Solid State Drive Duplicator
Technical Information
Operation Type: Standalone
Number of Destination Drives Supported: 2
Interfaces/Ports
Drive Interface:

• Serial ATA/600
• M.2

Host Interface: USB 3.2 (Gen 2) Type C
Power Description
Input Voltage:

• 120 V AC
• 230 V AC

Physical Characteristics
Color Family: Black
Product Color: Black
Form Factor: Compact
Drive Width:

• 3.5"
• 2.5"

Height: 55.9 mm
Width: 99.1 mm
Depth: 55 mm
Weight (Approximate): 292 g
Miscellaneous
Package Contents:

• M.2 NVMe/SATA Duplicator Dock
• 1 x USB-C Cable
• 2 x Rubber M.2 Standoff
• 1 x Power Adapter (NA/JP, UK, EU, ANZ)
• 1 x Quick-Start Guide

TAA Compliant: Yes
Environmental Compliance:

• Waste Electrical and Electronic Equipment Directive (WEEE)
• Restriction of Hazardous Substances (RoHS)

Warranty
Limited Warranty: 2 Year
