StarTech.com Docking Station

Marketing Information

Expand your workspace with a high-performance docking station that delivers triple 4K 60Hz display output, 2.5G Ethernet, and broad device connectivity, all through a single USB4 or Thunderbolt 4 connection.

High-Performance Display and Networking

Connect up to three 4K 60Hz displays via a single USB4 or Thunderbolt 4 port, leveraging full GPU capabilities without software or compression. Boost productivity with fast 2.5GbE networking, supporting PXE Boot and Wake-on-LAN for streamlined IT-managed deployments.

Comprehensive Connectivity and Power

The dock offers three video outputs (HDMI or DisplayPort), four USB-A ports (10Gbps), two USB-C ports (10Gbps and 5Gbps), and delivers up to 100W of host char...ging. A 180W power adapter ensures all ports operate at full capacity.

Driverless Deployment with Secure Mounting Options

Driverless setup with native Windows and ChromeOS support. Built-in lock slots and VESA or surface mounting options (accessories sold separately) provide secure, flexible installation.

Enterprise Management Tools

StarTech.com Connectivity Tools offer practical utilities to support device management and increase productivity in modern IT environments. With features like MAC address pass-through, Wi-Fi auto switch, and USB device monitoring, the software helps IT teams streamline deployment and strengthen security across diverse setups.

Visit www.StarTech.com/Connectivity-Tools to download the Enterprise Management Tools.

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: 150UE-USB4DOCKTRIPLE
Manufacturer Website Address: http://www.startech.com/uk
Brand Name: StarTech.com
Product Name: Docking Station
Packaged Quantity: 1
Product Type: Docking Station
Technical Information
Connectivity Technology: Wired
Charging Capability: Yes
Device Supported:

• Notebook
• Monitor
• Desktop PC
• Workstation

Cable Length: 1 m
Features:

• Power Delivery Pass-through
• Plug and Play

Management Features:

• PXE Boot
• Wake-on-LAN
• MAC Address Pass-through

Number of Displays Supported: 3
Screen Mode Supported:

• 4K @ 60Hz
• 4K @ 144Hz
• 4K

Supported Resolutions: 3840 x 2160
Maximum Data Transfer Rate: 5 GB/s
Security Slot Type: Kensington Security Slot
Network & Communication
Ethernet Technology: 2.5 Gigabit Ethernet
Interfaces/Ports
Host Interface: USB4
Total Number of USB Ports: 7
USB Type-A: Yes
Number of USB 3.2 Gen 2 Type-A Ports: 4
Number of USB Type-A Ports: 4
USB Type-C: Yes
USB Type-C Detail: 2 x USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
Number of USB Type-C Ports: 2
Network (RJ-45): Yes
Number of RJ-45 Ports: 1
DisplayPort: Yes
Number of DisplayPort Outputs: 3
Headphone/Microphone Combo Port: Yes
HDMI: Yes
Number of HDMI Outputs: 3
USB Power Delivery: 100W
Software
Operating System Supported:

• Windows 10
• Windows 11
• ChromeOS

Power Description
Maximum Power Supply Wattage: 180 W
Power Source Type: Power Adapter
Physical Characteristics
Color Family: Grey
Product Color: Space Gray
Miscellaneous
Package Contents:

• Docking Station
• 1 x 3 ft [1 m] USB4 Host Cable
• 1 x Universal Power Adapter (North America)
• 1 x Quick-Start Guide

Kensington Security Slot: Yes
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty: 3 Year
