Targus HyperDrive Thunderbolt 4 Docking Station

Marketing Information

The Thunderbolt 4 Docking Station is designed for enterprise businesses, PC gamers and video editors looking for an advanced connectivity solution that delivers maximum bandwidth and epic display resolutions. It features 2x Thunderbolt 4 Downstream ports capable of 40Gbps data transfers and 32Gbps PCIe transfers, and 1x Thunderbolt 4 Upstream port that provides 96W Power Delivery charging for your host device. Additionally, enjoy gaming and video editing like never before with dual 4K 60Hz display support through HDMI or Thunderbolt, an ultra-fast 2.5. Gigabit Ethernet connection, and high-resolution audio with the ability to choose between lifelike 8K 30Hz resolution or 4K 120Hz resolution to ensure faster rendering with less blur.

...2x TB4 Downstream Ports

Two Thunderbolt 4 downstream ports provide 40Gbps data transfers and 32Gbps PCIe transfers.

Dual 4K 60Hz Display Support

Supports dual 4K 60Hz display support through HDMI and/or Thunderbolt ports.

8K 30Hz or 4K 120Hz Resolution

Choose between beautiful 8K 30Hz resolution for more lifelike images or 4K 120Hz resolution to ensure faster rendering with less blur.

2.5 Gigabit Ethernet

With a 2.5 Gbps Ethernet connection, enjoy ultra-fast file transfers from NAS devices and never lose another game or match due to low bandwidth blues.

Hi-Res Audio

With audio performance up to 384Kz and 32bits, capture and listen to the big bangs or the smallest sound nuances, to maximise your gaming headset.

96W Power Delivery

Quickly charge your host computer with 96 watts of power when connected to an external Power Delivery charger.

High Speed USB-A

4x USB-A ports provide 10Gbps for transferring photos, files or high-resolution HD movies in under 30 seconds.

Specifications
Manufacturer: Targus Group International
Manufacturer Part Number: HDTB4DEU
Manufacturer Website Address: http://www.targus.com/uk/
Brand Name: Targus
Product Line: HyperDrive
Product Model: HDTB4D-EU
Product Name: HyperDrive Thunderbolt 4 Docking Station
Product Type: Docking Station
Technical Information
Connectivity Technology: Wired
Charging Capability: Yes
Device Supported:

• Monitor
• Desktop PC
• Tablet
• Notebook

Memory Card Reader: Yes
Memory Card Supported: SD
Features: Power Delivery Pass-through
Number of Displays Supported: 2
Screen Mode Supported:

• 8K @ 30Hz
• 4K

Supported Resolutions:

• 7680 x 4320
• 3840 x 2160

Maximum Data Transfer Rate: 5 GB/s
Network & Communication
Ethernet Technology: 2.5 Gigabit Ethernet
Interfaces/Ports
Host Interface: Thunderbolt 4
Total Number of USB Ports: 4
Number of USB Type-A Ports: 4
USB Type-A: Yes
USB Type-C: No
Network (RJ-45): Yes
Number of RJ-45 Ports: 1
Number of Network (RJ-45) Ports: 1
DisplayPort: No
Mini DisplayPort: No
Headphone/Microphone Combo Port: Yes
Number of HDMI Ports: 1
HDMI: Yes
Thunderbolt: Yes
Thunderbolt Ports Quantity: 3
Number of Thunderbolt 4 Ports: 3
USB Power Delivery: 96W
Software
Operating System Supported: Windows
Physical Characteristics
Color Family: Grey
Product Color: Grey
Height: 199.5 mm
Width: 74.8 mm
Depth: 31.1 mm
Weight (Approximate): 410 g
Miscellaneous
Compatibility:

Compatible Devices:

• Apple MacBook Pro 2016 or later
• Apple MacBook Air 2018 or later
• Apple iPad Pro 2021 or later
• Chrome OS laptop with Thunderbolt 3/4, USB 3.0 or later Type C with DP Alt-Mode
• Windows OS laptop with Thunderbolt 3/4, USB 3.0 or later Type C with DP Alt-Mode

Brand Compatibility: Apple
Warranty
Limited Warranty: 2 Year
