TP-Link AX1800 Wireless Dual Band Gigabit Router

Marketing Information

Highlights | Superior 5G + 4G LTE Speed

5G greatly boosts the download speed up to 4.67 Gbps. It brings fast responsive network connections with only 1 ms latency. At the same time, NX200 is backward compatible with 4G mode.

Powerful Wi-Fi 6

Archer AX1800 brings you incredibly fast dual-band speeds up to 3× faster than the previous AC generation of Wi-Fi, perfect for vivid 8K/4K streaming, intense online gaming, and more.

EasyMesh for Whole Home Coverage

The EasyMesh-compatible Archer NX200, can combine other APs together to form a powerful mesh Wi-Fi for full-home coverage and seamless roaming, eliminating Wi-Fi dead zones.

Better Signals for Connections Everywhere

...Three Gigabit Ethernet ports ensure stable connectivity, while two antenna ports boost signal strength.

Features | 5G Network

• 5G - Ideal for cutting-edge 5G network
• Backward Compatible - Compatible with 4G network

Wi-Fi Speed

• Superior Wireless Speed - Combined wireless speeds up to 574 Mbps over 2.4 GHz, and 1201 Mbps over 5 GHz
• 802.11 ax Standard- Provides a data transfer rate 3 times faster than 802.11ac for each stream

Wi-Fi Range

• Great Coverage - Better coverage with integrated Wi-Fi omnidirectional antennas

Reliability

• Simultaneous Dual Band - Separate Wi-Fi bands enable more devices to connect to your network without a drop in performance
• Easy Bandwidth Management - Advanced QoS makes it easier for you to manage the bandwidth of connected devices
• Superior Stability - Powerful processor enables you to connect up to 64 wireless devices with ease

Ease of Use

• Intuitive Web UI - Ensures quick and simple installation without hassle
• Fast Encryption - One-touch WPA wireless security encryption with the WPS button
• Wi-Fi On/Off - Conveniently turn on or off wireless radios as required
• Hassle-free Management with Tether App - Network management is made easy with the TP-Link Tether App, available on any Android and iOS device
• Online Upgrade - Keeps you informed of the latest firmware and allows online upgrade on the web UI

Security

• Guest Network - Keeps your main network secure by creating a separate network for friends and visitors
• Access Control - Establishes a whitelist or blacklist to allow or restrict certain devices to access the internet
• Parental Controls - Restrict internet access time and contents for your children's devices
• Encryptions for Secure Network - WPA, WPA2, and WPA3 encryptions provide active protection against security threats

Specifications
Manufacturer: TP-LINK Technologies Co., Ltd
Manufacturer Part Number: ARCHERNX200
Manufacturer Website Address: http://www.tp-link.com
Brand Name: TP-Link
Product Line: Archer
Product Model: NX200
Product Name: AX1800 Wireless Dual Band Gigabit Router
Product Type: Modem/Wireless Router
Technical Information
Wi-Fi Generation: Wi-Fi 6
Network Band: Dual Band
MU-MIMO Technology: Yes
Wireless Specifications
Broadband Transmission Technology:

• Ethernet
• Cellular

Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax
ISM Band: Yes
UNII Band: Yes
ISM Maximum Frequency: 2.40 GHz
UNII Maximum Frequency: 5 GHz
Cellular Generation: 5G
Cellular Network Supported:

• LTE 2100
• LTE 1800
• LTE 2600
• LTE 900
• LTE 800
• LTE 700
• LTE 2300
• LTE 2500
• LTE 3500
• LTE 3700
• UMTS 2100
• UMTS 850
• UMTS 900

Cellular Data Connectivity Technology:

• LTE
• DC-HSPA+
• HSPA
• UMTS

Total Number of Antennas: 10
Number of Internal Antennas: 10
Total Wireless Transmission Speed: 597.76 MB/s
Encryption Standard:

• WPA
• WPS
• WPA2
• WPA3
• WPA-PSK
• WPA2-PSK

Firewall Type: SPI
Wi-Fi Mesh System: Yes
Interfaces/Ports
Total Number of Network Ports: 3
Number of Network (RJ-45) Ports: 2
Number of Broadband (RJ-45) Ports: 1
Network & Communication
Ethernet Technology: Gigabit Ethernet
VPN Supported: Yes
Multi-SIM Supported: No
Number of SIM Card Supported: 1
SIM Size Supported: Nano
Physical Characteristics
Height: 190.5 mm
Width: 99.1 mm
Depth: 99.1 mm
Miscellaneous
Package Contents:

• AX1800 Wireless Dual Band Gigabit Router
• RJ45 Ethernet Cable
• Power Adapter
• Quick Installation Guide

Certifications & Standards:

CE

Environmental Compliance: Restriction of Hazardous Substances (RoHS)
