ViewSonic 24" IR Touch Monitor

Marketing Information

OVERVIEW

The ViewSonic® TD2423 is a 24" IR touch display designed for intuitive multi-touch use. Infrared (IR) touchscreen can detect up to 10 points of contact compared to optical touchscreens and can be operated by a stylus, fingers and gloved hands. The multi-touch input is more accurate, and the display is faster. Coupled with an adjustable tilt, you can easily interact with the TD2423 at an ideal position. This monitor features Full HD resolution to give you clear images and is built with scratch-resistant 7H hardness screen to surface damage. To support your work, the TD2423 is equipped with VGA, HDMI, DVI and USB connectivity.

Intuitive Multi-touch Experience

An infrared touchscreen tha...t can detect up to 10 points of contact under Windows compared to optical touchscreens, the TD2423 delivers an intuitive multi-touch experience with every tap, pinch, and swipe.

IR Touch Technology

Operating System Support

This monitor supports the main operating systems being Windows, macOS, Android, Chrome OS, Linux and Raspberry Pi.

Simple and Safer Way to Interact

This monitor can be operated by stylus and gloved hands, which improves hygiene and is effective for selection, dragging and drawing. What's more, there is a magnetic pen placeholder on the base.

Anti-scratch Touchscreen

With a built-in 7H hardness screen, it's resistant to surface damage caused by sharp objects.

7H Hardness Screen

Adjustable Tilt

This monitor includes an adjustable tilt, which allows you to easily tilt back up to 40-degrees, making it a good fit for anyone.

Clear Images

This monitor features Full HD 1920x1080 resolution to benefit you with greater image details and more displayable on-screen contents.

Full HD 1080p Resolution

Dual Integrated Speakers

With built-in 2-watt speakers, this monitor provides you a better audiovisual experience.

Enhanced Viewing Comfort

This monitor is built with Flicker-Free technology and a Blue Light Filter to reduce eye fatigue after a long day of use.

Specifications
Manufacturer: ViewSonic Corporation
Manufacturer Part Number: TD2423
Manufacturer Website Address: http://www.viewsoniceurope.com/uk/
Brand Name: ViewSonic
Product Model: TD2423
Product Name: 24" IR Touch Monitor
Product Type: LCD Touchscreen Monitor
Technical Information
Screen Size Class: 24"
Viewable Screen Size: 61 cm (24")
Screen Mode: Full HD
Panel Technology: Vertical Alignment (VA)
Response Time: 7 ms
Response Time Details: 7ms GTG (OD)
Aspect Ratio: 16:9
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Mount Type:

• Wall Mountable
• Desk Mountable

Backlight Technology: LED
Features:

• 7H Surface Hardness
• Cable Lock Slot
• Flicker-free
• Low Blue Light
• Scratch Resistant
• Eco Mode

Horizontal Frequency: 24 kHz to 82 kHz
Vertical Frequency: 50 Hz to 75 Hz
Stand Adjustments: Tilt
Video
Maximum Resolution: 1920 x 1080
Colour Supported: 16.7 Million Colours
Native Contrast Ratio: 3,000:1
Dynamic Contrast Ratio: 20,000,000:1
Brightness: 250 cd/m²
Color Gamut:

• 72% NTSC
• 104% sRGB

Audio
Speakers: Yes
Touchscreen Information
Touchscreen Type: Infrared
Multi-touch Screen: Yes
Number of Simultaneous Touchpoints: 10
Interfaces/Ports
DVI: Yes
HDMI: Yes
USB: Yes
VGA: Yes
Number of USB Ports: 3
Power Description
Operating Power Consumption: 16.50 W
Physical Characteristics
VESA Mount Compatible: Yes
VESA Mount Standard: 100 x 100
Height: 348 mm
Width: 571 mm
Depth: 61 mm
Height with Stand: 348 mm
Width with Stand: 571 mm
Depth with Stand: 101 mm
Weight (Approximate): 4.70 kg
Weight with Stand (Approximate): 5.20 kg
Miscellaneous
Energy Star: Yes
Environmental Certification:

• China Environmental United Certification Center (CEC)
• Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)

Energy Efficiency Certification:

• ENERGY STAR 8.0
• China Energy Conservation Program (CECP)

Energy Efficiency Compliance: Energy-related Products Directive (ErP)
Environmental Compliance:

• Restriction of Hazardous Substances (RoHS)
• Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
• Waste Electrical and Electronic Equipment Directive (WEEE)
• China Restriction of Hazardous Substances (China RoHS)
