Zebra 220Xi4 High Performance Industrial 8-inch Wide Standard

Marketing Information

Built for high-volume applications and harsh environments, Zebra's Xi Series label printers deliver superior print quality and reliability. Boost productivity with faster print and connection speeds, and reduce downtime with early warning.

Specifications
Manufacturer: Zebra Technologies Corporation
Manufacturer Part Number: 220-80E-00203
Manufacturer Website Address: http://www.zebra.com/gb/en
Brand Name: Zebra
Product Series: Xi4
Product Model: 220Xi4
Product Name: 220Xi4 High Performance Industrial 8-inch Wide Standard
Product Type: Direct Thermal/Thermal Transfer Printer
...rong>Technical Information
Recommended Use: Label Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 254 mm/s
Maximum Print Resolution (dpi): 203
Maximum Print Width: 215.90 mm (8.50")
Barcode Symbology Supported:

• Codabar
• Code 11
• Code 128
• Code 128-A
• Code 128-B
• Code 128-C
• Code 128 UCC
• Code 39
• Code 93
• EAN-13
• EAN-8
• ISBT-128
• Industrial 2 of 5
• Interleaved 2 of 5
• LOGMARS
• MSI
• Planet Code
• Plessey
• POSTNET
• Standard 2 of 5
• UPC 2 or 5 Digit Extension
• EAN With 2 or 5 Digit Extension
• UPC-A
• UPC-E
• Aztec Code
• Codablock
• Code 49
• Data Matrix
• Maxi Code
• Micro PDF
• PDF-417
• QR Code
• RSS
• GS1 DataBar
• TLC 39

Peel Facility: Yes
Rewinder: Yes
Features: LCD Display
Print Technology: Direct Thermal /Thermal Transfer
Memory
Standard Memory: 16 MB
Memory Technology: SDRAM
Flash Memory: 8 MB
Interfaces/Ports
Parallel Port: Yes
Serial Port: Yes
USB: Yes
Network & Communication
Ethernet: Yes
Ethernet Technology: Fast Ethernet
Media Types & Handling
Media Type:

• Continuous Form
• Black Mark
• Roll Fed
• Die-cut Label
• Fanfold

Media Sensor:

• Transmissive Media Sensor
• Reflective Media Sensor

Media Thickness: 304.8 µm
Maximum Roll Diameter: 81.28 mm
Maximum Label Width: 223.52 mm
Maximum Label Length: 3.81 m
Label Core Size: 25.40 mm
Ribbon Core Size: 25.40 mm
Fonts & Emulation
Language Emulation:

• ZPL
• ZPL II
• XML

Power Description
Input Voltage:

• 110 V AC
• 220 V AC

Physical Characteristics
Height: 393.7 mm
Width: 401.6 mm
Depth: 517.7 mm
Miscellaneous
Power Cable Localization: UK
Package Contents:

• 220Xi4 Network Thermal Label Printer
• Power Cord

Cables Included: AC
Additional Information:

• Unicode Compliant
• Intelligent printhead
• Auto calibration
• Clear Bi-fold Media Side Door
• Construction: 12-gauge steel frame
• Single 32 bit 133 Mhz RISC processor
• Automatic media/ribbon sensing capability
• Multi-level Element Energy Equalizer (E3) for superior print quality
• Mirror feature allows user-defined printer configurations to be retrieved from the network

Platform Supported: PC
Warranty
Limited Warranty: 1 Year
