Zebra SP72-V Vertical Single-Plane Scanner

Marketing Information

Simplify your checkout experience and improve your bottom line with high-performance in-counter and on-counter scanning

A long wait at the checkout line is the last thing a customer wants. One-quarter of shoppers have admitted to abandoning a purchase due to long lines.1 Speed up the checkout process, offer convenient self-checkout options and prevent lost sales with the SP72 Series. These high-performance single-plane scanners deliver everything you need to elevate the checkout experience in grocery, convenience, pharmacy and specialty stores. With innovative features, including an optional color camera to enable vision-based applications 2 , the SP72 Series scanner frees associates to do higher-priority tasks and better serv...e shoppers while minimizing the risk

of shrink. Available in both horizontal and vertical form factors, the SP72 Series fits wherever you need it-and is ideal for retailers that need the performance of a multi-plane scanner, but prefer the compact size, easy installation and value of a single-plane scanner.

Fast Checkouts for Manned and Self-Checkout Lanes

Create the Perfect Checkout Solution for Your Store

The compact vertical SP72-V can be placed on a counter or mounted on a wall or table; its flat face design easily fits into self-checkout enclosures and kiosks. The horizontal SP72-H offers a zero footprint, in-counter design and is a drop-in replacement for popular legacy installations. You can choose the level of features you need: SP7201 for high-performance scanning with all the essential features needed at the POS, or the premium SP7208 that offers the same high performance, plus more advanced features such as a color camera option for vision-based applications like loss prevention.

With "Swipe and Go" Scanning, Checkouts are Faster Than Ever

With high swipe speeds and a large reading area, the SP72 Series makes scanning second nature. Barcodes are captured as quickly as they're presented. Since there's less need to precisely position a barcode, cashiers can focus more on the customer and self- checkout users can enjoy a seamless experience.

Keep Every Checkout Lane Moving

Thanks to a high-resolution 2.3 megapixel sensor and Zebra's exclusive PRZM Intelligent Imaging technology, the SP72 Series offers unparalleled performance on virtually any 1D, 2D, Digimarc®, paper and mobile barcode. Poorly printed, damaged, crinkled, or faded barcodes-the SP72 Series can capture them all. And offset illumination enables trouble-free scanning of reflective barcodes on glass bottles, mobile phones or cellophane packaging.

Specifications
Manufacturer: Zebra Technologies Corporation
Manufacturer Part Number: SP7208SV4U2100TZW
Manufacturer Website Address: http://www.zebra.com/gb/en
Brand Name: Zebra
Product Series: SP72
Product Model: SP72-V
Product Name: SP72-V Vertical Single-Plane Scanner
Product Type: Barcode Scanner Kit
Technical Information
Connectivity Technology: Cable
Scanning Distance: 229 mm
Features:

• Checkpoint EAS
• Sensormatic EAS
• Beep
• Notification LED

Cable Type Included: USB
Field of View (Horizontal): 129°
Field of View (Vertical): 76°
Reading Angle (Skew): 70°
Reading Angle (Pitch): 80°
Reading Angle (Roll): 360°
Image Formats:

• BMP
• JPEG

Maximum Ambient Light: 86100 lux
Minimum Print Contrast: 15%
Minimum Element Resolution (Code 39): 0.08 mm
Maximum Element Resolution (Code 39): 0.25 mm
Minimum Element Resolution (DataMatrix): 0.13 mm
Maximum Element Resolution (DataMatrix): 0.38 mm
Maximum Element Resolution (PDF417): 0.38 mm
Image Sensor Resolution: 1920 x 1200
Illumination Type: LED
Illumination Color: Red
Interfaces/Ports
Host Interface: USB
Environmental Conditions
Operating Temperature: 0°C to 50°C
Storage Temperature: -40°C to 70°C
Humidity (Non-condensing): 20% to 95%
Physical Characteristics
Color Family: Black
Product Color: Midnight Black
Height: 137.2 mm
Width: 152.4 mm
Depth: 83.8 mm
Miscellaneous
Package Contents:

• SP72-V Vertical Single-Plane Scanner
• Mounts and Brackets
• USB Cable

Ingress Protection (IP) Rating: IP52
Application/Usage:

• Retail
• Pharmacy
• Convenience Store

Warranty
Limited Warranty: 3 Year
