Zebra SP72 Series Single-Plane Scanner

Marketing Information

Simplify your checkout experience and improve your bottom line with high-performance in-counter and on-counter scanning

A long wait at the checkout line is the last thing a customer wants. One-quarter of shoppers have admitted to abandoning a purchase due to long lines.¹Speed up the checkout process, offer convenient self-checkout options and prevent lost sales with the SP72 Series. These high-performance single-plane scanners deliver everything you need to elevate the checkout experience in grocery, convenience, pharmacy and specialty stores. With innovative features, including an optional color camera to enable vision-based applications², the SP72 Series scanner frees associates to do higher-priority ta...sks and better serve shoppers while minimizing the risk of shrink. Available in both horizontal and vertical form factors, the SP72 Series fits wherever you need it - and is ideal for retailers that need the performance of a multi-plane scanner, but prefer the compact size, easy installation and value of a single-plane scanner

Create the perfect checkout solution for your store

The compact vertical SP72-V can be placed on a counter or mounted on a wall or table; its flat face design easily fits into self-checkout enclosures and kiosks. The horizontal SP72-H offers a zero footprint, in-counter design and is a drop-in replacement for popular legacy installations. You can choose the level of features you need: SP7201 for high-performance scanning with all the essential features needed at the POS, or the premium SP7208 that offers the same high performance, plus more advanced features such as a color camera option for vision-based applications like loss prevention.

With "swipe and go" scanning, checkouts are faster than ever

With high swipe speeds and a large reading area, the SP72 Series makes scanning second nature. Barcodes are captured as quickly as they're presented. Since there's less need to precisely position a barcode, cashiers can focus more on the customer and self-checkout users can enjoy a seamless experience.

Keep every checkout lane movingThanks to a high-resolution 2.3 megapixel sensor and Zebra's exclusive PRZM Intelligent Imaging technology, the SP72 Series offers unparalleled performance on virtually any 1D, 2D, Digimarc®, paper and mobile barcode. Poorly printed, damaged, crinkled, or faded barcodes - the SP72 Series can capture them all. And offset illumination enables trouble-free scanning of reflective barcodes on glass bottles, mobile phones or cellophane packaging.

Specifications
Manufacturer: Zebra Technologies Corporation
Manufacturer Part Number: SP7208SV4U2100ZCW
Manufacturer Website Address: http://www.zebra.com/gb/en
Brand Name: Zebra
Product Series: SP72
Product Model: SP72-V
Product Name: SP72 Series Single-Plane Scanner
Product Type: Barcode Scanner Kit
Technical Information
Connectivity Technology: Cable
Scanning Capability:

• 1D
• 2D

Barcode Symbology Supported:

• Code 39: 3 mil - SP72-V: 0 in. to 3.8 in./0 cm to 9.7 cm
• Code 39: 10 mil - SP72-V: 0 in. to 8.1 in./0 cm to 20.6 cm
• Code 128: 3 mil - SP72-V: 0 in. to 3.3 in./0 cm to 8.4 cm
• Code 128, 15 mil - SP72-V: 0 in. to 9.0 in./0 cm to 22.9 cm
• PDF417, 15 mil - SP72-V: 0 in. to 7.6 in./0 cm to 19.2 cm
• 100% UPCA, 13.0 mil - SP72-V: 0 in. to 8.6 in./0 cm to 21.8 cm
• Data Matrix, 5 mi - SP72-V: 0.2 in. to 2.6 in./0.5 cm to 6.5 cm
• Data Matrix, 15 mil - SP72-V: 0 in. to 6.6 in./0 cm to 16.8 cm
• QR, 20 mil - SP72-V: 0 in. to 7.5 in./0 cm to 19.1 cm

Scanner Range: Standard Range
Scanning Distance: 229 mm
Features:

• Checkpoint EAS
• Sensormatic EAS
• Beep
• Notification LED

Cable Type Included: USB
Field of View (Horizontal): 54°
Field of View (Vertical): 36°
Reading Angle (Skew): 70°
Reading Angle (Pitch): 80°
Reading Angle (Roll): 360°
Image Formats:

• JPEG
• RAW

Maximum Ambient Light: 86100 lux
Minimum Print Contrast: 15%
Minimum Element Resolution (Code 39): 0.08 mm
Maximum Element Resolution (Code 39): 0.25 mm
Minimum Element Resolution (DataMatrix): 0.13 mm
Maximum Element Resolution (DataMatrix): 0.38 mm
Maximum Element Resolution (PDF417): 0.38 mm
Image Sensor Resolution: 1920 x 1200
Illumination Type: LED
Illumination Color: Red
Air Electrostatic Discharge (+/-): 15kV
Interfaces/Ports
Host Interface:

• USB
• Serial
• Keyboard Wedge

Environmental Conditions
Operating Temperature: 0°C to 40°C
Storage Temperature: -40°C to 70°C
Humidity (Non-condensing): 20% to 95%
Physical Characteristics
Form Factor: In-counter
Color Family: Black
Product Color: Black
Height: 137.2 mm
Width: 152.4 mm
Depth: 83.8 mm
Weight (Approximate): 577 g
Miscellaneous
Package Contents:

• SP72 Series Single-Plane Scanner
• Scanner
• Cable

Ingress Protection (IP) Rating: IP52
Application/Usage:

• Retail
• Pharmacy
• Convenience Store

Warranty
Limited Warranty: 3 Year
Additional Warranty Information:

Subject to the terms of Zebra's hardware warranty statement, the SP72 Series, is warranted against defects in workmanship and materials for a period of Three Years from the date of shipment.
