Zebra ZT231R Thermal Transfer Printer

Marketing Information

AFFORDABLE, INDUSTRIAL RFID PRINTING/ENCODING

Today's supply chain is driving the need for real-time omni-channel visibility, end-to-end transparency and rigorous safety and compliance. At the same time, your production costs are escalating and timelines are shrinking. Stay competitive with RFID. Zebra's ZT231 RFID introduces affordable, quality UHF RFID printing and encoding for greater tracking capabilities and efficiencies - all in a space-saving footprint.

New to RFID? Zebra's intuitive RFID technology is easy to adopt. Access wizards for simple set up. Automatically calibrate media in minutes without pre-testing or complex placement guidelines. As your tracking needs advance, know you're backed by our unmatched RFID... portfolio.

THE RFID PRINTER THAT WORKS FOR YOU AND YOUR BUDGET | Meet Escalating Compliance Requirements

More retailers now require products to include RFID labels. Meet this need without breaking your budget. The ZT231 RFID delivers easy-to-use, quality RFID printing and encoding at a price you can afford.

Simple to Adopt, Easy to Use

Whether you're new to RFID or a seasoned pro, Zebra's own RE40 module makes RFID printing and encoding intuitive and flexible. Maximize your choice of media with our adaptive encoding array and auto calibration features. Rely on the ZT231 RFID to encode the right tag and quickly produce crisp barcodes, texts and graphics with 300 dpi resolution at 8 ips.

ADVANCE YOUR RFID CAPABILITIES | With the Broadest, Field-Proven Portfolio

As you're incorporating RFID solutions, take advantage of Zebra's unrivaled portfolio of RFID printers, readers, sensors and inlays to give you a competitive edge and stay ahead of advancing technology. No matter your needs, know you're backed by an industry leader with decades of proven expertise.

INNOVATIVE SOLUTIONS FOR TODAY AND TOMORROW | Get the Most Out of Your Workspace

Want industrial printing capabilities but don't have the workspace to accommodate it? The ZT231 RFID gives you the power and features you need in a compact footprint. Plus, its bi-fold door reduces the height of the printer when open. But don't let its compact size fool you - it can accommodate a large ribbon roll so you can print longer without changing media.

Make Work Easier

The ZT231 RFID is easy to install, use and manage with Zebra's Print DNA^TMsuite of apps. Reduce training time and see printer status at a glance with the large color touchscreen. Change RFID settings with the touch of a finger or gloved hand. Get your questions answered with helpful, how-to videos.

The Smart Choice Now and Long Term

The benefits of buying a ZT231 RFID don't end at the point of purchase. Expand your printer's capabilities with field-installable media-handling or connectivity upgrades when you need them.

Durable and Intelligent to Last for Years

Future-proof your printing with the long-lasting quality and innovation you expect from Zebra. The ZT231 RFID features a durable, metal frame to handle light-industrial environments. It's engineered to evolve with printing and RFID technology advancements to give you years of performance.

Specifications
Manufacturer: Zebra Technologies Corporation
Manufacturer Part Number: ZT23142T0E00CFZ
Manufacturer Website Address: http://www.zebra.com/gb/en
Brand Name: Zebra
Product Series: ZT200
Product Model: ZT231R
Product Name: ZT231R Thermal Transfer Printer
Product Type: Thermal Transfer Printer
Technical Information
Recommended Use: Label Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 304.80 mm/s
Maximum Print Resolution (dpi): 203
Maximum Print Length: 3.99 m
Maximum Print Width: 104 mm (4.09")
Barcode Symbology Supported:

• Code 11
• Code 39C
• Code 93
• Code 128 (A/B/C)
• UCC Case Codes
• ISBT-128
• UPC-A
• EAN-8
• UPC-E
• EAN-13
• UPC-A with EAN 2 or 5 Digit Extension
• Plessey
• POSTNET
• Standard 2 of 5
• Industrial 2 of 5
• Interleaved 2 of 5
• LOGMARS
• Codabar
• MSI
• Planet Code
• AZTEC
• Codablock
• PDF417
• Code 49
• Data Matrix
• Maxi Code
• QR Code
• Micro PDF-417
• TLC 39
• RSS-14
• RSS Composite

Real Time Clock: Yes
Application/Usage:

• Manufacturing
• Transportation & Logistic
• Healthcare
• Retail
• Industrial

Print Technology: Thermal Transfer
Memory
Standard Memory: 256 MB
Interfaces/Ports
Serial Port: Yes
USB Host: Yes
USB: Yes
Network & Communication
Ethernet: Yes
Ethernet Technology: Ethernet
Bluetooth: Yes
RFID: Yes
Display & Graphics
Display Screen: Yes
Screen Size: 10.9 cm (4.3")
Display Screen Type: LCD
Cutter
Cutter: Yes
Cutter Type: Tear Bar
Media Types & Handling
Media Type:

• Continuous Label
• Label
• Die-cut Label
• Notch
• Black Mark

Media Sensor:

• Transmissive Media Sensor
• Reflective Media Sensor

Media Thickness: 250 µm
Maximum Roll Diameter: 203 mm
Maximum Label Width: 114 mm
Maximum Label Length: 18 mm
Fonts & Emulation
Language Emulation:

• ZBI 2.0
• ZPL II
• ZPL

Power Description
Power Source: AC Supply
Frequency:

• 50 Hz
• 60 Hz

Environmental Conditions
Operating Temperature: 4.4°C - 40.6°C
Operating Relative Humidity: 20% - 85%
Storage Temperature: 4.4°C - 60°C
Storage Relative Humidity: 5% - 85%
Miscellaneous
Power Cable Localization:

• EU
• UK

Certifications & Standards:

IEC 62368-1, EN55022 Class B, EN55024, EN55035, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus, CE Marking, UKCA, VCCI, RCM, S- Mark, CCC, CU EAC, BSMI, KCC, & BIS

Energy Star: Yes
