ZYXEL 5-Port GbE Unmanaged Switch

Marketing Information

5/8-Port GbE Unmanaged Switch

The GS-105B v5 and GS-108B v5 are the most compact desktop switches newly introduced in Zyxel Switching portfolio. These two mini-sized 5-port and 8-port desktop unmanaged switches connect network devices for studio or small office network at Gigabit speed. The QoS ports guarantee high quality of video or voice data transmission.

Benefits | Fast, reliable wired connectivity

Without any manual configuration, the GS-105B v5/GS-108B v5 can boost data transfer speed for connected network devices such as IP phones, network storages, PCs and laptops to the network at Gigabit speed just with plug-and play.

Mini, sturdy switch with alternative wall-mount design

The co...mpact size of the GS-105B v5/GS-108B v5 fits most network installations in your office, whether placed on a desktop or wall-mounted. The durable metal housing design withstands physical impacts and dissipates heat more efficiently, ensuring a stable network experience, better performance, and increased longevity.

Optimized for smooth VoIP and data exchange

The GS-105B v5 and GS-108B v5 feature with 3 and 4 QoS ports respectively. The QoS ports come with an assigned high- and medium-priority mechanism to enhance the stability of VoIP and data exchange. Just connect network devices such as IP phones, PCs, laptops or network storages to the high-priority or medium-priority ports of your choice, you can then enjoy smooth VoIP communication and data transfer at the same time.

Green switch saves energy

Compliant with the IEEE 802.3az Energy Efficient Ethernet standard, the GS-105B v5/GS-108B v5 offers power-saving benefits by detecting link status and consuming power more efficiently, all without compromising performance. The fanless design ensures all-time silent operation. They are perfect for noise-free working environments.

Specifications
Manufacturer: ZYXEL Communications Corp.
Manufacturer Part Number: GS-105BV5-GB0101F
Manufacturer Website Address: http://www.zyxel.co.uk
Brand Name: ZYXEL
Product Model: GS-105B v5
Product Name: 5-Port GbE Unmanaged Switch
Product Type: Ethernet Switch
Technical Information
Features:

• Fanless
• Plug and Play
• Energy Efficient

Interfaces/Ports
Total Number of Network Ports: 5
Network (RJ-45): Yes
Port/Expansion Slot Details: 5 x 100/1000BASE-T Gigabit Ethernet RJ -45 Network Port
Media & Performance
Media Type Supported: Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology: 100/1000Base-T
Maximum Data Transfer Rate: 128 MB/s
Network & Communication
Layer Supported: 2
Networking Standards:

• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3x
• IEEE 802.3az

Management & Protocols
Manageable: No
Reliability
MTBF: 259047 Hour
Power Description
Input Voltage:

• 120 V AC
• 230 V AC

Frequency:

• 50 Hz
• 60 Hz

Power Source:

• Power Adapter
• AC

Power Consumption: 2.99 W
Physical Characteristics
Product Material: Metal
Form Factor:

• Desktop
• Wall Mountable

Height: 24 mm
Width: 82.5 mm
Depth: 46.8 mm
Weight (Approximate): 110 g
Miscellaneous
Package Contents:

• 5-Port GbE Unmanaged Switch
• Power Adapter
• Rubber Foot
• Wall Mount Kit
• Safety Warning and Doc

Application/Usage:

• Network
• IP Phone
• PC
• Laptop
• Small Office
• Office
• Router

Certifications & Standards:

• CE
• EAC
• FCC
• BSMI Class B
